About this part
22100-54311 is supplied as a remanufactured replacement fuel injection part. Cross-reference numbers: 22100-54311, 09600-3070. Application recorded for this part: Fits Toyota — Hilux Hiace 2L-T 2.4L.
The injector sits at the end of the rail and does the final metering work: it receives fuel already at high pressure and decides both how much enters the cylinder and how well atomised it is. That combination governs power, smoke and fuel consumption more directly than almost any other part on the engine.
Symptoms that point to injector wear include hard starting when hot, rough idle, white smoke at start-up or black smoke under load, a sharp knocking from one cylinder, increased fuel consumption and a gradual loss of power.
Do a return-flow check before buying anything. Comparing leak-off volumes between cylinders takes minutes, and if one injector returns far more than its neighbours, that single test has answered the question.
Fit as a matched set rather than singly — one new injector among worn neighbours reproduces the uneven running you set out to cure. New sealing washers every time, clean seats, correct torque, and where applicable, program the injector codes into the ECU once fitted.
Rebuild process: full teardown and measurement first, then replacement of all wear components, machining back to specification where required, followed by calibration and bench testing. The difference between this and a cleaned used part is the measurement and test record — we hold every unit to the specification for the part number, not just to 'it runs'. Test sheets available on request, and every unit ships with a 12-month warranty.
Specifications
| Part number | 22100-54311 |
| Condition | Remanufactured (not a genuine OEM new part) |
| Cross-reference | 22100-54311, 09600-3070 |
| Application | Fits Toyota — Hilux Hiace 2L-T 2.4L |
| Process | Disassembled, cleaned, measured, wear parts replaced, machined to specification |
| Bench test | Delivery, return flow, opening pressure and leakage recorded before dispatch |
| Warranty | 12 months |
Fitment note. Several part numbers in this family look similar. Confirm the number on your
existing unit, the engine model and the machine or vehicle application before ordering. Send us a nameplate photo
and we will verify the match before dispatch.
All manufacturer names, symbols and part numbers are used for identification and cross-reference purposes only. We are not an authorised distributor and are not affiliated with the original equipment manufacturer. Products offered are remanufactured or new aftermarket replacement parts unless stated otherwise.
